Operating Theater Standard Package
State-of-the-art surgical environment with premium medical-grade materials and advanced control systems
Anti-Bacterial Design
Medical-grade materials with HRP anti-bacterial properties throughout the OR
Advanced HVAC System
Precision temperature (18-24°C) and humidity (40-60%) control with HEPA filtration
Smart Control System
Touch screen interface for complete environmental control and monitoring
Key Features of Our Standard OT Package
Medical Insulated Panels
50mm thick HRP anti-bacterial panels with magnesium board core and Germanium white finish
Laminar Air Flow System NEW
1800x1800mm SUS304 stainless steel unit with built-in lighting and optional door configurations
Hermetic Sliding Doors
1600x2120mm automatic doors with safety sensors and medical rubber seals
Complete Package Specifications
Everything included in our Standard Operating Theater Package
| No | Component | Specifications | Qty | Unit |
|---|---|---|---|---|
| 1 | Dinding & Ceiling OT | Medical Insulated Panel dengan HRP Anti Bacterial, Ketebalan 50mm, warna Putih Germanium, bahan Magnesium Board | 1 | OK |
| 2 | Antibacteria PVC floor | Vinyl Anti Bacterial, Anti Statis, Anti Jamur, anti korosi, Tebal 2,0mm standard USA Ambiance Ultra, ketahanan tinggi, termasuk Leveling Lantai, Double Colour dan Polishing | 1 | OK |
| 3 | Automatic Hermetic system Sliding Door | 1600 * 2120 * 12mm 1. Door material Galvanis / Stainless Steel Warna sesuai permintaan 2. door frame: Aluminum Extrusion w. Medical Rubber 5. opening/closing speed: 350-650mm/sec 6. opening 7. safety function: Obstacle can open immediately when opening and closing power: 220V±10% 50/60HZ |
1 | set |
| 4 | Manual Swing door w | 900*2100*42mm | ||
| 5 | Medicine & Instrument cabinet | 900*1800*350 mm 1. Door material Coated Colour frame: Aluminum Extrusion w. Medical Rubber with Double tempered Glass Aluminum 2. door frame: Aluminum Extrusion w. Medical Rubber with Double tempered Glass Aluminum 3. Rail material: |
1 | set |
| 6 | Laminar Air Flow OK Minor | 1800 x 1800 x 520 mm 1. 1mm SUS304 hair line stainless steel 2. swing or sliding door optional 3. Tempered Glass and Built in Lighting Inside |
1 | unit |
| 7 | Power socket box | Universal Power Socket, Germany Standard | ||
| 8 | LED Panel light | 1200*300mm 220V 50HZ, mengellingi Laminar dengan standar tingkat keterangan memnuni permenkes 24 tahun 2016 |
||
| 9 | MEDICAL PASSBOX | Material : SUS 304#, with Double Door Mechanical Interlocking system, Built in UV-Light Sterilizer, Alarm for Door Opening System, Double Glazed Tempered Glass | ||
| 10 | Outlet Medical Gass | ONAGSS, diessuaikan permintaan JIS/DIN/EU/Jaimiya. Termasuk instalasi ke dinding luar bangunan | ||
| 11 | HVAC DX | Air Handling Unit dengan system Higienis, Suhu dan Kelembaban terukur melalui PLC dan HMI Remote Touch Screen dengan Pressure/Tekanan ruangan tercontrol secara otomatis Temperature 18-24 Celcius, Kelembaban 40-60%, Aliran udara Laminar, Filtrasi dengan Pre Filter dan Medium Filter , Pengontrolan Kelembaban dengan electric Heater, Tekanan Udara Positive Pressure), ACH 20-40x/jam |
||
| 12 | Operating theare Control system | Pengatur sistem Kamar Operasi, sistem tombol TOUCH SCREEN yang dilengkapi dengan Pengaturan Suhu, Kelembaban, Jam kerja, Jam Actual, Music Player, Speaker, Ventilasi system Exhaust on/off, dan dengan Rangka SUS 304# | 1 | set |
| 13 | Room Pressure Monitor Analog | built integrated with OT Control system | 1 | set |
| 14 | Trafo Isolasi | ETKAO | 1 | set |
| 15 | UPS OK Minor | 5 Kva Termasuk Instalasi, dan Online system, Phase in and 3 phase out |
1 | set |
| 16 | X-Ray Film Viewer | 2 bay | 1 | set |
| 17 | Jasa Pemasangan PENDANT & Support | 1 | set | |
| 18 | BIAYA PENDUKUNG PEKERJAAN | Transport & Akomodasi Teknisi, Biaya Drawing, Approval, Pengiriman Material & Keamanan Proyek, | 1 | ls |
